TAYLEX- at the forefront of advanced wastewater treatment
Taylex Advanced Wastewater Treatment Systems use natural processes to turn wastewater into clean, safe water, which is recycled on-site. With over 55 years of experience, Taylex is a trusted leader in home sewage treatment systems.
If your property is not connected to a council sewer, you need to treat your household wastewater on-site using a Home Sewage Treatment System. Taylex offers a flexible, future-ready solution. Ideal for off-grid or regional living, our systems are trusted across Australia for their durability and low maintenance.
How does a Taylex work?
The Taylex system is a fully integrated, multi stage treatment plant contained within a single tank. These systems are supported by current regulatory approvals, strong real world performance data and design suitable for remote and environmentally sensitive locations.
Primary & Secondary Pre-Treatment
Separation of solids and initial organic load reduction is just the beginning of the treatment process.
Traditional Septic Systems provide NO further treatment and the waste water is now released into the environment.
Aeration Chamber
Fitted with bio block media, disk diffuser/s and air lift. The high‑efficiency bio‑media and low‑wattage blower support aerobic digestion of organic matter
Clarification & Filtration
Settling and disk filtration remove remaining suspended solids, with sludge return to the primary chamber.
Disinfection & Irrigation
Using less chlorine per liter than an average swimming pool, the system removes any harmful bacteria, viruses and pathogens and then pumps the crystal clear water out for irrigation re-use.
Systems to suit every situation
Taylex 1500 Poly & Concrete (10 people)
The Taylex 1500 (poly PABS design shown) Advanced Secondary Treatment System (STS) is designed treat wastewater up to 10 persons per day.
· Hydraulic Loading Capacity: 1,500 L/day (10 EP)
· Treatment Level: Advanced Secondary
· Tank Construction: Polyethylene or concrete
· Daily Energy Consumption: 2.21 kWh/day
Taylex Polymer Tanks are designed to accommodate site conditions where it is not possible to crane in a concrete treatment system. The unique polymer mould cleverly uses 'Sandwich closed-cell foam polymer' to mould the compartment walls in one piece. There are no joins or glued-in compartments, and all partitions extend to the lid of the tank.
Taylex 2000 NR Poly & Concrete (13 People)
The Taylex 2000NR (concrete ABS design shown) Advanced Secondary Treatment System (STS) with Nutrient Reduction is designed for higher‑use facilities or environmentally sensitive discharge areas.
· Capacity: 2,000 L/day (13 EP)
· Treatment Level: Advanced Secondary
· Tank Construction: Polyethylene or concrete
· Daily Energy Consumption: 2.5 kWh/day
Taylex Commercial Systems - 33 + people
The Taylex ABS5000 Advanced Secondary Treatment System (STS) is contained in two vertical axis type cylindrical precast concrete collection wells with a design capacity of 11,062 Litres per tank, a combined operating capacity of 14,451 Litres and emergency storage of 7,673 Litres.
· Capacity: 5,000 L/day (33 EP)
· Treatment Level: Advanced Secondary
· Tank Construction: Concrete
· Daily Energy Consumption: 6.16 kWh/day
Contact us for more information on larger commercial systems.
